Piezo buzzer EPT1360A-TO-05-4.0-08-5.0-R 5V piezoelectric transducer -ESUNTECH

Quantity:

13mmx6mm pin buzzer 5V  4000hz 1360 1306 passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


5.0

Model No. EPT1360A-TO-05-4.0-08-5.0-R
Rated Voltage (Vp-p) 5
Operating Voltage (Vp-p) 1~30
Resonant Frequency (Hz) 4000±500
Capacitance 120Hz (PF) 8000±30%
*Sound Output at 10cm (dB) ≥80
*Current Consumption (mA) ≤3
Operating Temperature (℃) -20~+70
Storage Temperature (℃) -30~+80
Weight (g) 0.8
RoHS Yes

3
