Piezo ceramic buzzer EPT1470A-TO-05-4.0-15-7.6-R piezoelectric transducer -ESUNTECH

Quantity:
  • EPT1470A-TO-05-4.0-15-7.6-R

14mmx7mm pin buzzer 5V  9V 12V 4000hz 1470 1407 passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

MODEL EPT1470A-TO-05-4.0-15-7.6-R
Rated Voltage (Vp-p) 5
Resonance Frequency (KHz) 4.0±0.5
Max Input Voltage (Vp-p) 25
Rated Current (mA) ≤3
Capacitance at 120Hz (pF) 15000±30%
Sound Output at 10cm (dB) ≥85
Operating Temperature (℃) -20~+70
Storage Temperature (℃) -30~+80
Weight (g) 0.8
RoHS Yes

3
