Piezo electric buzzer EPB4333SP-TA-12-2.9-7.5-R big power buzzer -ESUNTECH

Quantity:
  • EPB4333SP-TA-12-2.9-7.5-R

43mmx33mm Piezo buzzer 2/3 pin continuous pulse tone 2900hz 4333 alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model EPB4333SP-TA-12-2.9-7.5-R
Rated Voltage (VDC) 12
Operating Voltage (VDC) 5~28
*Rated Current (mA) ≤20
*Sound Output at 30cm (dB) ≥95
*Resonant Frequency (Hz) 2900±500
Tone Fast Pulse /Continuous
Operating Temperature (℃) -20~+65
Storage Temperature (℃) -30~+70
Weight (g) 38
Housing Material ABS
RoHS Yes
