Piezo pin transducer EPT2270D-TC-03-2.0-27-12.5-R 3V wash machine alarm -ESUNTECH

Quantity:
  • EPT2270D-TC-03-2.0-27-12.5-R

22mmx7mm square buzzer 3V 6V 2khz 2270 2207  alarm annunciator  passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for washing machine...household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model EPT2270D-TC-03-2.0-27-12.5-R
RATED VOLTAGE  (Vp-p) 3
OPERATING VOLTAGE  (Vp-p) 1~30
RATED CURRENT  (mA) ≤3
RESONANT FREQUENCY  (Hz) 2000±500
CAPACITANCE AT 120Hz  (PF) 27000±30%
SOUND PRESSURE LEVEL  (dB) ≥75
OPERATING TEMPERATURE  (℃) -20~+70
STORAGE TEMPERATURE  (℃) -30~+85
WEIGHT  (g) 2.5
RoHS Yes

3
