Piezo wireless annunciator EPT3075AD-TO-10-2.5-20-15.0-R 12V high-output alarm buzzer -ESUNTECH

Quantity:
  • EPT3075AD-TO-10-2.5-20-15.0-R

30mmx7.5mm pin buzzer 3V 6V 12V 2500hz 3075 alarm annunciator  passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No. EPT3075AD-TO-10-2.5-20-15.0-R
Rated Voltage (Vp-p) 12
Operating Voltage (Vp-p) 1~30
Resonant Frequency (Hz) 2500±500
Capacitance 120Hz (PF) 20000±30%
*Sound Output at 10cm (dB) ≥85
*Current Consumption (mA) ≤10
Operating Temperature (℃) -20~+60
Storage Temperature (℃) -30~+70
Weight (g) 3.2
Case material and colour PPO/ Black
Rohs Yes

3
