Piezo wireless transducer EPT2207-TO-12-4.0-15-10.0-R 12V high-output alarm annunciator -ESUNTECH

Quantity:
  • EPT2207-TO-12-4.0-15-10.0-R

22mmx5mm wireless buzzer 3V 6V 12V 4000hz 2207 alarm annunciator  passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

MODEL EPT2207-TO-12-4.0-15-10.0-R
Rated Voltage (Vp-p) 12
Resonance Frequency (Hz) 4000±500
Max Input Voltage (Vp-p) 30
* Rated Current (mA) ≤12
Capacitance at 120Hz (pF) 12000±30%
* Sound Output at 10cm (dB) ≥90
Operating Temperature (℃) -20~+60
Storage Temperature (℃) -30~+70
Weight (g) 2.5
ROHS Yes
