Piezoelectric buzzer EPT1325W605-TA-05-5.0-15-R 5V wired piezo transducer -ESUNTECH

Quantity:
  • EPT1325W605-TA-05-5.0-15-R

13mmx3.5mm wired buzzer 5V  5000hz 1325 passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No. EPT1325W605-TA-05-5.0-15-R
Rated Voltage (Vp-p) 5
Operating Voltage (Vp-p) 1~25
Resonant Frequency (Hz) 5000±500
Capacitance 120Hz (PF) 15000±30%
*Sound Output at 10cm (dB) ≥80
*Current Consumption (mA) ≤3
Operating Temperature (℃) -20~+60
Storage Temperature (℃) -30~+70
Weight (g) 1
RoHS Yes
