SMD Piezo transducer EPT1410S-HS-10-4.3-14-R 10V 14mm-ESUNTECH

  • EPT1410S-HS-10-4.3-14-R
Quantity:

14mm*14mm*10mm 10V 1410 SMD passive piezo transducer & buzzer square buzzer buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No. EPT1410S-HS-10-4.3-14-R
Rated Voltage (Vp-p) 10
Max Input Voltage (Vp-p) 20
Rated Current (mA) ≤10
Resonance Frequency (Hz) 4300±500
Capacitance at 120Hz (pF) 14000±30%
Sound Output at 10cm (dB) ≥90
Operating Temperature (℃) -20~+70
Storage Temperature (℃) -30~+80
Weight (g) 2.3
Housing Material PPS
RoHS Yes
