mechanical wired buzzer EMB2316 12V electromechanical buzzer -ESUNTECH

Quantity:
  • EMB2316W1005-06-0.4-R

23mmx17mm continuous  tone sound mechanical buzzer  6V 9V 12V 24V 400hz 2316 2317 alarm annunciator transducer & buzzer  high quality  alarm buzzer for household electrical appliances,meter and instrument - Changzhou Esuntech Co Ltd.


2


Model EMB2316W1005-06-0.4-R
Rated Voltage (VDC) 6
Operating Voltage (VDC) 3~7
Resonant Frequency (Hz) 400±100
*Rated Current (mA) 30
*Sound Output at 20cm (dB) 80
Operating Temperature () -20+60
Storage Temperature () -30+70
Weight (g) 8.4
Housing Material ABS
Rohs Yes

12V
