small magnetic transducer EET9650 low voltage annuciator-ESUNTECH

Quantity:
  • EET9650BB-1.5O-2.731-5.5-4.0-R

9.6mmx5mm 1.5V  5.5 OHM 2731hz 9650 9605  passive electromagnetic transducer & buzzer square  buzzer Anunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model EET9650BB-1.5O-2.731-5.5-4.0-R
Rated Voltage (V) 1.5
Operating Voltage (V) 12
Resonant Frequency (Hz) 2731
Coil Resistance (Ω) 5.5±1
*Sound Output at 10cm (dB) ≥85
*Current Consumption (mA) ≤100
Operating Temperature () -25+70
Storage Temperature () -30+80
Weight (g) 0.8
Housing Material PPO
Rohs Yes
